Comprehensive overview of our HDPE pipe specifications, standards, and performance parameters.
| PARAMETER | SPECIFICATION |
|---|---|
| Pipe Diameter Range | 20mm to 1600mm (3/4" to 63") |
| Pressure Ratings | PN 2.5, PN 4, PN 6, PN 8, PN 10, PN 12.5, PN 16 |
| Standard Dimension Ratio | SDR 7.4, SDR 9, SDR 11, SDR 13.6, SDR 17, SDR 21, SDR 26 |
| Operating Temperature | -40°C to +60°C (-40°F to +140°F) |
| Service Life | 50+ years under standard conditions |
| Material Density | 0.941 - 0.965 g/cm³ (PE80 & PE100 grades) |
| Certification Standards | IS 4984, ISO 4427, EN 12201, AWWA C906 |
| Joint Type | Butt Fusion, Electrofusion, Mechanical Couplings |
| Coil Lengths | 50m, 100m, 150m, 200m (customizable) |
| Country of Origin | 🇮🇳 India |
Our HDPE pipes are designed with cutting-edge technology to deliver unmatched performance across demanding applications.
HDPE pipes exhibit outstanding resistance to a wide range of chemicals, acids, and alkalis, making them ideal for industrial and municipal applications.
High-density polyethylene offers excellent flexibility while maintaining structural integrity, enabling installation across diverse terrains and conditions.
Heat fusion joints create a monolithic, leak-proof pipeline system that eliminates the risk of joint failures and reduces maintenance costs significantly.
With a 50+ year service life and minimal maintenance requirements, HDPE pipes deliver exceptional value over their operational lifetime.
HDPE is 100% recyclable and has a significantly lower carbon footprint compared to traditional piping materials like steel, ductile iron, or PVC.
Every pipe undergoes rigorous quality testing and conforms to international standards including ISO 4427, IS 4984, and EN 12201.
HDPE (High-Density Polyethylene) pipes are thermoplastic pipes known for their high strength-to-density ratio. They are manufactured from petroleum-based polyethylene material and are widely used for water supply, gas distribution, sewage systems, and industrial applications. Their flexibility, corrosion resistance, and long service life make them superior to traditional piping materials.
HDPE pipes offer numerous advantages: superior chemical resistance, leak-proof fusion joints, exceptional flexibility, 50+ year service life, lightweight for easy handling, corrosion-free operation, and environmental sustainability through 100% recyclability.
HDPE pipes are manufactured through an extrusion process. Raw polyethylene pellets are melted and pushed through a die to form the pipe shape. The extruded pipe then passes through vacuum sizing, water cooling, and haul-off units before being cut to specified lengths or wound into coils.
HDPE pipes are used in potable water supply, sewage and drainage systems, gas distribution, industrial process piping, mining slurry transport, irrigation systems, telecom ducting, marine outfall systems, and landfill leachate collection.
Yes, HDPE pipes can be extensively customized in terms of diameter (20mm to 1600mm), pressure ratings, wall thickness, coil lengths, and color coding. We also offer custom fittings and accessories to meet specific project requirements.
Get our complete product catalogue delivered straight to your inbox.
The manufacturing process begins with careful selection and testing of high-quality PE80 and PE100 grade polyethylene resin. Raw materials are sourced from certified suppliers and undergo rigorous quality checks before entering the production line.
"We have been using Gushwork HDPE pipes for our municipal water supply projects for over 5 years. The quality is consistently excellent, and the fusion joints have shown zero leakage."
"The Gushwork team provided comprehensive technical assistance during our gas distribution network installation. Their PE100 pipes exceeded pressure test requirements by 20%."
"Switching to Gushwork HDPE pipes reduced our maintenance costs by 40%. The pipes have been performing flawlessly for 8 years across our irrigation network covering 500 hectares."
"Gushwork delivered 12km of large-diameter HDPE pipes within the committed timeline. Their logistics and on-site support made our mining project installation seamless."
Complete range of HDPE fittings including elbows, tees, reducers, flanges, and electrofusion couplers for seamless pipeline integration.
End-to-end pipeline installation services including surveying, trenching, pipe laying, fusion welding, and hydrostatic testing.
High-performance PE-RT pipes designed for underfloor heating, radiator connections, and hot water distribution systems.
Get a customized quote for your piping requirements. Our engineering team will analyze your project needs and provide the optimal HDPE solution.
